Characteristics
category
Mattress base
Comfort
Handling
Safety
Base supported on adjustable legs
Height adjustment system using telescopic column
Height adjustment from 83 to 123 cm
Optional: 4 wheels of 125 mm of diameter
Ergonomic adaptation and maximum comfort necessary to improve the quality of life and health of users
PUR padded patient leg support
The backrest joint is operated by means of a gas piston, which is easy and comfortable to use.
Trendelenburg position with inclination of up to 21º
The legrest is foldable and easily removable, allowing a wide variety of configurations
Seat and backrest made of high-density polyurethane foam, designed for optimal comfort and ergonomic suitability
Upholstered in self-extinguishing vinyl fabric
Technical file
Dimensions
- Dimensions: 1850 x 600 x 650/900 mm
- Backrest dimensions: 800 x 600 mm
- Pelvis dimensions: 410 x 600 mm
- Legrest dimensions: 300 x 600 mm
Technical data
- Height: 830 a 1230 mm
- Backrest tilt: 70º
- Trendelemburg: 21º
- Weight without accessories: 92 kg
Accessories
Armrest padded in PUR
Roll holder support
Colposcopy support
Adjustable proctology device
Normative
The product complies with the European directive EU 2007/47/EC and controlled under the quality management system EN ISO 9001:2015
