Characteristics
category
Generals
Generals
Comfort
Funcionality
Mobility
Scissor lifting system with electric drive using a low-consumption linear motor.
Two independent sections with headrest articulated in multiple positions using a 700 N gas spring, which extends the life of the piston and provides greater stability against lateral loads.
Extremely solid and stable high-quality steel structure, with epoxy coating.
The bed base lifting system has great dynamic stability and resistance to load, being able to support up to 230 kg
Cushions: padding made of cold-molded, high-resilience flexible polyurethane foam, 55mm thick and high density. Lined with self-extinguishing vinyl fabric, antibacterial and resistant to absorption and stains. Fireproof according to M2 standard,
Rounded edges with no edges and seamless upholstery, which prevents liquids from entering the interior and makes cleaning and disinfection easier.
Adjustable backrest section by means of drives
Ergonomic breathing opening with padded lid
Padding made of high-density polyurethane foam
Upholstered in self-extinguishing vinyl fabric
Maximum seating space for both therapist and patient
Headboard/footboard with great firmness and stability against lateral loads
Adjustable by means of a gas spring in multiple positions and angles that allows any type of treatment to be performed
Tilting angle from -15º to 74º
Adjustable height controlled by electric motor with continuous movement and operation on both sides of the Plinth by foot control. (*optional hand control, upon
request)
Double swivel wheels, Ø 65 mm in diameter, retractable using bilateral pedal, with retractable locking/unlocking system and synchronized drive
Highly efficient centralized simultaneous braking
Legs with non-slip rubber and adjustable levelers on each leg to compensate for possible uneven floors.
Technical file
Technical data
Dimension patient surface: 196 x 69cm
*(Possibility of manufacturing in other sizes, upon request)
Height adjustment: 49 x 88cm
Headrest inclination: -15º to 74º
Maximum load capacity: 230 kg
Weight without accessories: +/-45 kg
Electric motor potential: 8.000N
Factory margin may vary by up to 1cm.
NOTE: Measures and features of the products may be changed without prior notice.
Accessories
Included accessories
Roll holder support attached to the structure.
Ergonomic breathing opening with padded lid.
Personalization product
Our products are customizable, each Hospital Center can include, remove or modify
the specifications and options of our furniture (dimensions, wheel diameter Ø,color of the upholstery, thickness of the padding, finishes, accessories, etc. ) to fully adapt it to your installation and the needs of both the user and the staff, thus making an exclusive and different product.
Normative
The OMEGA BASIC 2 transport stretcher meets the essential requirements of Regulation 2017/745 for medical devices and controlled under the quality management system EN ISO 9001-2015
Regulations: IEC/EN 60601-1 IEC/EN 60601-2
