Characteristics
categoria
Bed base
Design and comfort
Management
Security
- Structure made of steel tube with epoxy coating
- Headboard and footboard fixing system, without the need for tools
- Bed movements and height adjustments through three motors
- Side arches, which prevent movement of the mattress
- Lifting systems supported by compasses that provide great stability in any position and allow a load of up to 230 kg
- Rubber bumpers on each corner of the bed
- Three independent and removable modules made of ABS. 100% useful surface
- Antibacterial polyurethane upholstery
- Adjustment of the height and joints of the bed base planes using low-voltage electric motors, complying with EN 60601-1 regulations.
- Trendelenburg 16º
- Actuation of the pelvic area electrically 17º
- Set of independent side rails made of ABS that facilitates the incorporation of the user as a support point
- Height elevation from 560 mm to 960 mm by electric drive
- Centralized and servo-directed braking system. Ø150mm double band wheels
- Manual keypad with easy-to-read and easy-to-use pictograms
- Bed function override device
- Includes battery
- Thermoplastic lower fairing that protects the bed mechanisms and makes cleaning easier
- Anti-collapse system in the lifting actuators in case of failure
- Anti-pinch system with automatic engine stop when an obstacle is detected
- Trunk plane emergency release system that allows rapid lowering of the plane in case of emergency, battery failure or power failure
Technical file
Technical data
- Total length: 202 cm
- Backrest length: 85 cm
- Width with side rails: 103 cm
- Height from floor to seat section: 54 – 97.5 cm
- Backrest inclination angle: 70º
- Trendelenburg position: 21º
- Maximum bed load: 250 kg
- Accessory cart: 66 x 112 x 99 cm
Electric characteristics
- Power supply: 230V 50 Hz
- Maximum Consumption: 1.6A, 370 Volt
- Protection indicator: IP 5A
- Protection class: Class I
- Degree of protection against discharge: TYPE B
Accessories
- Accessory cart
- Mattress
- Arm support
- IV stick support
- Legrest
- Tray
- Battery
- Manual CPR
- Support framework
Normative
All products manufactured by MEDISA comply with directive 2007/47/EEC on medical devices (Annex I and Annex VII)
In the same way, all its processes have been evaluated and certified according to the requirements of the UNE-EN ISO 9001:2015 Quality Management standard, the UNE-EN ISO 14001:2015 Environmental Management standard and the UNE-ENE ISO 13485:2016 Quality Management of health products standard
MEDISA products are subject to regulations EN-ISO 14971, EN-ISO 15223-1, EN-ISO 13485, EN 60601-1, EN 60601-1-2, EN 60601-2-52, EN 60601-1-6 , EN 60601-1-8, EN 62366.
Certified by CSQ: CERTIFICATES Nº 9120.MDIB, Nº 9191.MDI2, Nº 9124.MIBE.
Reach: design, manufacturing, marketing and technical assistance of hospital beds and chairs. Marketing of hospital furniture.º
